Dimensions

• Height: 58” (147 cm)
• Width: 12.5” (31.75 cm)
• Depth: 11.5” (29.21 cm)
• Weight: 113 lbs (51.26 kg)

Displays

• There are two displays on the PB 980. The primary display and the status display.
• Size: 15”
• ovements: 170° rotation about a vertical axis in either direction; 45° tilt from a vertical position.

Pneumatic Specifications

• Oxygen and Air Inlet Supplies: Pressure: 241 to 600 kPa (35 psi to 87 psi); Flow: Maximum of 200 L/min
• Gas Mixing System: Up to 80 L/min for pediatric circuit type; Up to 150 L/min for adult patients.; Additional flow is available (peak flow to 200 L/min) for compliance compensation.
• Maximum Limited Pressure (PLIM max): Limits circuit pressure to < 125 cmH2O (123 hPa) at the patient wye
• Maximum Working Pressure (PW max): PW max is ensured by the high-pressure limit when PI is 90 cmH2O (88.26 hPa)

Measuring Devices

• Pressure Measurements: Type: Solid-state differential pressure transducer; Sensing position: Inspiratory module, expiratory module
• Flow and Volume Measurements: Type: Hot film anemometer; Sensing position: Inspiratory module, expiratory module; Type: Proximal flow sensor option utilizes differential pressure; Sensing position: Patient wye
• Oxygen Measurement: Type: Galvanic cell; Sensing position: Inspiratory module
• Oxygen Sensor Life: Up to one year; operating life varies depending on oxygen usage and ambient temperature

Filtration Capabilities

• Internal Inspiratory Filter Bacterial/Viral Filtration Efficiency: > 99.999%
• Internal Inspiratory Filter Particle Filtration Efficiency: >99.97% retention of particles 0.3 μm nominal at 100 L/min flow
• Exhalation Filter Resistance (Adult/Pediatric, Disposable): <0.7 cmH2O at 30 L/min (new); <0.35 cmH2O at 15 L/min
• Expiratory Filter Bacterial/Viral Filtration Efficiency: > 99.999%
• Exhalation Filter Particle Filtration Efficiency, Pediatric/Adult, Disposable: Maximum of 0.03% penetration of particles 0.3 μm nominal at 30 L/min flow

Parameters

• Predicted Body Weight (PBW): 3.5 kg (7.7 lb) to 150 kg (330 lb)
• Modes: Assist Control (A/C), Synchronized Intermittent Mandatory Ventilation (SIMV), Spontaneous (SPONT), BiLevel, Continuous Positive Airway Pressure (CPAP)
• Mandatory Breath Types: Volume Control (VC), Pressure Control (PC), and Volume Control Plus (VC+)
• Spontaneous Breath Types: Pressure Support (PS), Volume Support (VS), Tube Compensation (TC), and Proportional Assist Ventilation PAV+ software
• Ventilation Type: Invasive and Noninvasive (NIV)
• Pressure Support (PSUPP): 0 cmH2O to 70 cmH2O
• Rise Time %: 1% to 100%
• Expiratory Sensitivity (ESENS): 1% to 80%; 1 L/min to 10 L/min with PAV+
• Tidal Volume (VT): 25 mL to 2,500 mL; Resolution: 0.1 mL for values <5 mL; 1 mL for values 5 mL to 100 mL; 5 mL for values 100 mL to 395 mL; 10 mL for values ≥400 mL
• Respiratory Rate (ƒ): 1.0 1/min to 100 1/min; 1.0 1/min to 150 1/min with Puritan Bennett 980 Universal ventilator
• Peak Inspiratory Flow (VMAX): 3 L/min to 150 L/min
• Plateau Time (TPL): 0.0 to 2.0 seconds
• Inspiratory Pressure (PI): 5 to 90 cmH20
• Inspiratory Time (TI): 0.2 to 8.0 seconds
• I:E Ratio: 1:299 to 149:1
• Expiratory time (TE): ≥ 0.20 seconds; Resolution: 0.01 s
• Trigger Type: Pressure-triggering (P-TRIG) or flow-triggering (V-TRIG)
• Pressure sensitivity (PSENS): 0.1 cmH2O to 20 cmH2O
• Flow sensitivity (VSENS): 0.2 L/min to 20 L/min
• O2%: 21% to 100%
• Positive end expiratory pressure (PEEP): 0 cmH2O to 45 cmH2O
• Apnea Ventilation Mandatory Type: PC, VC
• Apnea Peak Inspiratory Flow (VMAX): 3.0 L/min to 150 L/min
• Apnea Tidal Volume (VT): 25 mL to 2,500 mL
• Apnea Inspiratory Pressure (PI): 5 cmH20 to 90-PEEP cmH20
• Apnea Interval (TA): Apnea interval (TA) 10 to 60 seconds or Off in CPAP
• Apnea Respiratory Rate (ƒA): 2.0 1/min to 40 1/min and ≥60/TA
• Apnea O2%: 21% to 100% O2
• Apnea I:E Ratio: ≤ 1.00:1
• Apnea inspiratory time (TI): 0.20 to 8 seconds
• Apnea expiratory time (TE): 0.20 to 59.8 seconds
• Disconnect Sensitivity (DSENS): 20% to 95% or Off (when Puritan Bennett™ ventilator with Leak Sync software is disabled); 1 L/min to 65 L/min (when Puritan Bennett ventilator with Leak Sync software is enabled)
• Humidification Type: Heat-moisture exchanged (HME), non-heated expiratory tube, heated expiratory tube
• Humidifier Volume: 100 mL to 1,000 mL
• Patient Circuit Type: Pediatric and adult

Respiratory Maneuvers

• Negative Inspiratory Force (NIF): ≤ 0 cmH2O to ≥ -50 cmH2O
• P0.:1 ≥ -20 cmH2O to 0 cmH2O
• Vital capacity (VC): 0 mL to 6,000 mL

Advanced Displayed Patient Data

• % Leak: 0% to 100%
• Inspiratory Leak Volume (VLeak): 0 mL to 9,000 mL
• Leak: 0 L/min to 200 L/min
• Spontaneous Rapid Shallow Breathing Index (f/VT): 0.1 1/min-L to 600 1/min-L
• Dynamic Resistance (RDYN): 0 cmH2O/L/s to 100 cmH2O/L/s
• Dynamic Compliance (CDYN): 0 mL/cmH2O to 200 mL/cmH2O
• Inspiratory Compliance (C20/C): 0 to 1.00
